Synology DiskStation DS223j 2 Bay Diskless NAS
Warranty and Support
Warranty and Support
Warranty: 2 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Built for sharing
DS223j is designed for small teams to share, sync, and collaborate more efficiently.
Multi-platform file access
Manage your files and media from anywhere with Synology Drive. Available on PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser.
Real-time collaboration
Stay productive while working in a team or with your clients. Work together across different platforms using Synology Office.
Sync across sites
Keeping data synced between different sites has never been easier. Synology Drive ShareSync keeps files and folders synchronized across Synology systems.
Seamless synchronization to clouds
Sync files between your private cloud and public cloud storage platforms, including Google Drive, Dropbox, Microsoft OneDrive, and more with Synology Cloud Sync. Retain local copies of your cloud data to centralize management and achieve data ownership.
Your data in safe hands with Btrfs
The advanced Btrfs file system helps safeguard data against corruption through file self-healing and allows for the reversal of unintentional or malicious changes through fast snapshot technology.
Store, share, and protect
Configure your DS223j to manage all your documents, photos, and other files, or protect your physical assets with professional video surveillance.
Photo management
- Manage your photo collection: Organize your photos and videos with smart and intuitive features. Browse automatically generated albums using facial recognition, geolocation, tags, and more.
- Sharing made safer and easier: Securely share media with colleagues or clients while leveraging privacy-focused options for your peace of mind. Collaborate with selected users on a folder-based media library by creating a Shared Space.
Data protection
- Automated media backup: Automatically upload photos and videos taken on your mobile device to your private cloud with Synology Photos or Synology Drive.
- Protection against cyberattacks: Leverage Synology Drive to protect data from ransomware attacks or accidental deletion with real-time or scheduled backup of your PC folders.
Video surveillance
- Wide compatibility: Choose from over 8,300 IP cameras or ONVIF devices compatible with Synology Surveillance Station to keep your premises secure.
- Universal access: Watch live camera streams through web browsers, desktop clients, or mobile apps. Get notified of events and take immediate action.
Specifications
Specifications
CPU Model | Realtek RTD1619B |
CPU Quantity | 1 |
CPU Core | 4 |
CPU Architecture | 64-bit |
CPU Frequency | 1.7 GHz |
Hardware Encryption Engine | Yes |
System Memory | 1 GB DDR4 non-ECC |
Notes | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. |
Drive Bays | 2 |
Compatible Drive Type | 3.5" SATA HDD 2.5" SATA SSD (with optional 2.5" Disk Holder) |
Hot Swappable Drive | - |
Notes | "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. |
RJ-45 1GbE LAN Port | 1 |
USB 3.2 Gen 1 Port | 2 |
Notes | This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. |
Size (Height x Width x Depth) | 165 mm x 100 mm x 225.5 mm |
Weight | 0.88 kg |
System Fan | 92 mm x 92 mm x 1 pcs |
Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode Low-power Mode |
Brightness Adjustable Front LED Indicators | Yes |
Power Recovery | Yes |
Noise Level | 18.2 dB(A) |
Scheduled Power On / Off | Yes |
Wake on LAN / WAN | Yes |
Power Supply Unit / Adapter | 60 watts |
AC Input Power Voltage | 100V to 240V AC |
Power Frequency | 50/60 Hz, Single Phase |
Power Consumption | 16.31 watts (Access) 4 watts (HDD Hibernation) |
British Thermal Unit | 55.62 BTU/hr (Access) 13.64 BTU/hr (HDD Hibernation) |
Notes | For more information on how power consumption is measured, refer to this article. Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75ËšC; Humidity: 58.2-61.8% |
Operating Temperature | 0°C to 40°C (32°F to 104°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
Relative Humidity | 5% to 95% RH |
Certifications | FCC CE BSMI VCCI RCM UKCA EAC CCC KC |
