Silverstone RM41-H08 4U 5 x 3.5” Hot-Swappable Server Chassis
In stock at Computer Lounge
Couldn't load pickup availability
Warranty and Support
Warranty and Support
Warranty: 1 Year Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Distinctive exterior
Distinctive front panel features a handle design allowing for easy accessibility to the internal components, along with two USB 3.0 data transfer ports.
Storage device performance
Supports SAS 12G/ SATA 6Gb/s high-speed transfer with a hot-swappable and tray-free design
Storage bays
Offers users a wide range of hard drive options including support for 5.25"/3.5"/2.5" hard drives and slim optical drives
Internal configurations
- Length limitation: 7.87” (200mm)
- Supports ATX (PS2) / Mini Redundant
- Supports up to SSI-CEB (12" x 10.5") motherboards
Cooling capabilities
Utilizing the typical front-to-back directional airflow, RM41-H08 comes pre-installed with two 80mm PWM fans for exhaust, designed to achieve a rapid heat dissipation effect that does not easily accumulate hot air inside
Specifications
Specifications
| Model No. | SST-RM41-H08 |
| Chassis form factor | 4U |
| Motherboard | SSI-CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7") |
| Material | SGCC |
| Main metal thickness | 1.2mm |
| Drive Bay | External 5.25" x 3, 3.5" x 5 (Hot-swappable) Internal 3.5" x 4, 2.5" x 2 (Support up to 15mm), 2.5" x 1 (Support up to 15mm) or slim optical drive (Support up to 12.7mm) |
| Power Supply | PS2 / ATX / Mini Redundant (supports up to 200mm), 2U Redundant (V2.0 or after) |
| Cooling system | Front 80 x 25mm fan slot x 1 Rear 80 x 25mm fan slot x 2 (both fans included) Internal 80mm fan x 1, 3000rpm (on hot-swap cage) |
| Limitation of CPU cooler | Height w/ expansion card retainer: 130mm Height w/o expansion card retainer: 148mm |
| Expansion card | Length w/ 5.25” drive cage: 278mm Length w/o 5.25” drive cage: 426mm |
| Expansion Slot | 7 standard PCI / PCIe expansion slots |
| Front I/O Port | USB 3.1 Gen1 Type-A x 2 |
| Front buttons | Power On / Off, restart |
| Indicators | Power status x 1, system reset x 1, network status x 2 |
| Dimension | 430mm (W) x 176mm (H) x 446mm (D) |
| Net Weight | 10.7 kg |
