Fractal Design Prisma AL-18 PWM 180mm RGB Case Fan - OEM Packaging
In stock at Computer Lounge
Couldn't load pickup availability
Warranty and Support
Warranty and Support
Warranty: 2 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
SHOP STORE:
Description
Description
Prisma AL-18 PWM
The Prisma AL-18 is a powerful 180 mm ARGB fan that packs a mean punch in the airflow department. Massive blades, stout 38 mm thickness, and wide 300-1200 RPM range with PWM control allow the AL-18 to yield remarkably high airflow while remaining exceptionally quiet.
- Massive 180 x 38 mm RGB fan that yields remarkably high airflow while remaining very quiet
- Twelve individually addressable hub-mounted RGB LEDs
- Specially designed fan blades and outer ring produce an exceptionally uniform glow
PWM precision
PWM control with a wide 300-1200 RPM speed range ideal for radiators
Trip Wire technology introduces a micro-turbulent layer for enhanced blade efficiency
Aerodynamic stator struts with embedded wiring reduce noise and turbulence
Manually Controllable
Adjust R1 RGB controller (sold separately) enables physical control of colors and effects
Fits standard 180 mm fan mounts with 165 x 165 mm screw hole pattern
Black sleeved power cables offer an extra touch of style
Maximum compatibility
Compatible with ASUS AURA, Gigabyte Fusion, MSI Mystic Light, ASRock Polychrome and Razer Chroma
High-grade LLS bearing
Long-Life Sleeve bearing with 90,000-hour MTTF delivers long-lasting dependability
Smooth operation
Integrated synthetic rubber corners nullify fan vibrations
Chained connections
Chain RGB cables to simplify wiring and run multiple fans or additional RGB devices from a single connector
Specifications
Specifications
| Size | 180 x 180 x 38 mm |
| Color | Black frame, white blades |
| Screw Hole Pattern | 165 x 165 mm |
| LED Type | Addressable RGB |
| Power Connector | 4-pin |
| Bearing | LLS |
| Number of Blades | 7 |
| Rotational Speed | 300 – 1200 RPM |
| Noise Level | 14.9 – 37.4 dB(A) |
| Max Airflow (CFM) | 43.1 – 146.8 CFM |
| Max Airflow (m³/h) | 73.27 – 249.56 m³/h |
| Max Pressure | 0.44 – 2.50 mmH2O |
| Fan Input Power | 4.2W at 12VDC |
| Fan Max Input Current | 0.35A |
| Fan Input Voltage | 12V |
| Minimum Startup Voltage | 6V |
| LED Rated Voltage | 5V |
| LED Rated Current | 0.6A |
| LED Rated Input Power | 3.0W |
| MTTF | 90,000 hrs |
| Fan Weight | 521 g (1.043 kg 2-pack) |
| Cable Length | 1000 mm |
| Cable Type | Black sleeved |
