Fractal Design Node 804 mATX USB3.0 Case - Black

Fractal Design  |  SKU 21876  |  MPN FD-CA-NODE-804-BL-W
$229.00

In stock at Computer Lounge

Warranty and Support

Warranty: 2 Years Return to Base Warranty

Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.

Delivery and Shipping

All deliveries are signature required.

North Island: 1 – 2 working days
South Island: 2 – 3 working days

Please allow an additional 1 – 2 working days for delivery to rural addresses.

Buy Now, Pay Later & Finance Options:

Description

The Node 804 is a micro ATX chassis which focuses on cooling performance and maximum configurability, all packed in an interesting new form factor with Scandinavian elegant design.The dual chamber layout separates hot running components from the cooler ones and allows for unrestricted airflow over the motherboard, processor and graphics card.The case comes with three excellent 120mm fans but can be upgraded with several additional fans if needed.Featuring plenty of options for placing water cooling components, tall heat sinks and hard drives.The flexibility of this case really gives the users the possibility to create their optimal system build.


    KEY FEATURES

  • Highly effective dual chamber case layout for best possible cooling.
  • Minimalistic design with an elegant brushed aluminum front panel
  • Unique hard drive mounting system, fitting up to 8 x 3.5″, 4 x 2.5” or up to 10 x 3.5”, 2 x 2.5″ drives HDD/SSD
  • Three Fractal Design Silent Series R2 fans included with the case and space for an additional 7 fans.
  • Excellent water cooling support with space for up to 4 radiators simultaneously.
  • All intakes feature removable dust filters providing a dust-free interior.
  • Featuring a window side panel to show off your set up in style.
  • Additional space in the front to mount a slim slot-in ODD, optical bay drive, and 2 x 2.5″ drives.
  • Fan controller included.
  • Five expansion slots that allows for multiple GPU setups.

Specifications

3,5" HDD positions8
2,5" SSD positions2
Extra positions for either 3,5″ or 2,5″ drives2
Expansion slots5
Front ports2x USB 3.0, Audio in/out, Power button with LED (blue), HDD activity LED (white)
Total fan mounts10
Front fan4x 120 mm
Top fan4x 120/140 mm
Rear fan 11x 120/140 mm (included is 1 hydraulic bearing 120 mm Silent Series R2 fan @ 1000 RPM)
Rear fan 21x 120 mm (included is 1 hydraulic bearing 120 mm Silent Series R2 fan @ 1000 RPM)
Dust filtersFront fans, Top fans, Bottom
Fixed velcro strapsYes
Left side panelClear window
Right side panelSteel
Power supply typeATX
Motherboard compatibilityMicro ATX, Mini ITX
Front radiator (left chamber)240 mm (up to 60 mm thick (with fans) and 278 mm tall; using a radiator in this position prevents the use of a fan in the top position just next to it)
Front radiator (right chamber)240 mm (up to 60 mm thick (with fans) and 278 mm tall)
Top radiator (left chamber)240 mm (up to 130 mm thick (with fans); radiators in this position limits the height of memory modules to 48 mm tall)
Top radiator (right chamber)240/280 mm (up to 130 mm thick (with fans) may be fitted if the HDD drive bays are taken out or placed elsewhere)
PSU max length260 mm
GPU max length320 mm, 290 mm (if a fan is installed in the lower position in the front)
CPU cooler max height160 mm
Case dimensions (WxHxD)344 x 307 x 389 mm
Net weight6 kg
Package dimensions (WxHxD)370 x 468 x 412 mm
Package weight7.7 kg
Volume40.3 liters

Package contentNode 804 computer case, accessory box & user manual
EAN7350041082019
UPC817301012010
Product codeFD-CA-NODE-804-BL-W
