Fractal Design Define 7 Mid Tower Black Tempered Glass Light Tint
In stock at Computer Lounge
Couldn't load pickup availability
Warranty and Support
Warranty and Support
Warranty: 2 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Re-defining versatility.
The Define 7 is the latest pinnacle of the renowned Define series, setting anew standard for what you should expect from a mid-tower case when it comes to modularity, flexibility and ease of use. The dual-layout interior,industrial sound damping, and classic styling make it an easy choice for any design-conscious PC builder in need of a versatile and dependable case that accommodates ambitious builds and leaves you room to grow.
GENEROUS SPACE
Define 7’s roomy internal layout easily accommodates large motherboards up to and including E-ATX.
FLEXIBLE DUAL-LAYOUT DESIGN
You’ll find more than enough space for your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout.
OPEN AND INTERCHANGEABLE
- Remove the entire top to build and route with zero hindrance. Swap in the ventilated panel to add three filtered fan positions.
- Tool-less, top-latching panels allow quick access while preventing accidental drops
ELEGANT NEW FRONT DESIGN
Brushed aluminum encases a refined front door design with dual-handed reversible hinges and magnetic latching.
SUPERIOR AIRFLOW
Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.
- The single 5.25” ODD bay can be converted to an additional 140 mm front fan mount with filtered louver covering
- Silence-optimized construction with industrial sound-damped front, top, and side panels
- New chassis design opens up to fully expose the case interior for totally unhindered installation and cable routing
- Two vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
- Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
- Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
- Redesigned HDD cage for easier installation and improved transportation security
- Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
- Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support
- Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
- Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board
SUPERLATIVE STORAGE
Convert to Storage Layout and install up to 14 HDDs alongside four dedicated SSDs mounts. (6 SSD/HDD trays + 2 SSD brackets + 1 multi-brackets included)
EXCEPTIONALLY SILENT
Solid construction with industrial high-density sound damping helps maintain whisper silent operation.
VERSATILE NEW MULTI-BRACKETS
The included multi-bracket lets you convert any unused fan position to an HDD, SSD or pump mount.
Specifications
Specifications
3.5"/2.5" Universal drive brackets | 6 included, 14 positions total |
Dedicated 2.5" drive brackets | 2 trays included, 4 positions total |
5.25” drive mounts | 1 |
Expansion slots | 7 + 2 |
Front ports | 1 x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button |
Total fan mounts | 9 x 120/140 mm |
Front fan | 3 x 120/140 mm (2 x Dynamic X2 GP-14 included) |
Top fan | 3 x 120/140 mm |
Rear fan | 1 x 120/140 mm (1 x Dynamic X2 GP-14 included) |
Bottom fan | 2 x 120/140 mm |
Dust filters | Top, 2 x front, full length bottom |
Fixed velcro straps | Yes |
Cable routing grommets | Yes |
Captive thumbscrews | HDD brackets, SSD brackets, PSU bracket |
Left side panel | Industrial sound-damped steel or Tempered Glass |
Right side panel | Industrial sound-damped steel |
Motherboard compatibility | E-ATX (max 285 mm) / ATX / mATX / mITX |
Power supply type | ATX |
PSU max length | 250 mm (with HDD cage installed) |
GPU max length | Storage layout: 290 mm - Open layout: 470 mm (445 mm w/ front fan) |
CPU cooler max height | 185 mm |
Front radiator | Up to 360/280 mm |
Top radiator | Up to 360/420 mm |
Rear radiator | 120 mm |
Bottom radiator | Up to 240/280 mm |
Cable routing space | 30 mm |
Vertical GPU Support (with Flex B-20 or Flex VRC-25) | 65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling |
Case dimensions (LxWxH) | 547 x 240 x 475 mm |
Case dimensions w/o feet/protrusions/screws | 533 x 240 x 451 mm |
Package dimensions (LxWxH) | 558 x 363 x 641 mm |
Net weight | Solid Version: 13.49 kg, TG Version: 13.45 kg |
Package weight | Solid Version: 15.98 kg TG Version: 15.94 kg |
Volume | 57.7 liters |
Package contents | Define 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6) |
