Fractal Design Define 7 Mid Tower Black Tempered Glass Light Tint

Fractal Design  |  SKU 34575  |  MPN FD-C-DEF7A-02
$349.00

In stock at Computer Lounge

Warranty and Support

Warranty: 2 Years Return to Base Warranty

Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.

Delivery and Shipping

All deliveries are signature required.

North Island: 1 – 2 working days
South Island: 2 – 3 working days

Please allow an additional 1 – 2 working days for delivery to rural addresses.

Buy Now, Pay Later & Finance Options:

Description

Re-defining versatility.

The Define 7 is the latest pinnacle of the renowned Define series, setting anew standard for what you should expect from a mid-tower case when it comes to modularity, flexibility and ease of use. The dual-layout interior,industrial sound damping, and classic styling make it an easy choice for any design-conscious PC builder in need of a versatile and dependable case that accommodates ambitious builds and leaves you room to grow.


GENEROUS SPACE

Define 7’s roomy internal layout easily accommodates large motherboards up to and including E-ATX.


FLEXIBLE DUAL-LAYOUT DESIGN

You’ll find more than enough space for your custom water loop with large reservoirs and radiators up to 420 mm in the default Open Layout.

OPEN AND INTERCHANGEABLE

  • Remove the entire top to build and route with zero hindrance. Swap in the ventilated panel to add three filtered fan positions.
  • Tool-less, top-latching panels allow quick access while preventing accidental drops


ELEGANT NEW FRONT DESIGN

Brushed aluminum encases a refined front door design with dual-handed reversible hinges and magnetic latching.


SUPERIOR AIRFLOW

Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of nine fans.

  • The single 5.25” ODD bay can be converted to an additional 140 mm front fan mount with filtered louver covering
  • Silence-optimized construction with industrial sound-damped front, top, and side panels
  • New chassis design opens up to fully expose the case interior for totally unhindered installation and cable routing
  • Two vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
  • Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
  • Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
  • Redesigned HDD cage for easier installation and improved transportation security
  • Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
  • Ventilated PSU shroud with two-part removable cover for optimal coverage and front radiator support
  • Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
  • Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board

SUPERLATIVE STORAGE

Convert to Storage Layout and install up to 14 HDDs alongside four dedicated SSDs mounts. (6 SSD/HDD trays + 2 SSD brackets + 1 multi-brackets included)


EXCEPTIONALLY SILENT

Solid construction with industrial high-density sound damping helps maintain whisper silent operation.


VERSATILE NEW MULTI-BRACKETS

The included multi-bracket lets you convert any unused fan position to an HDD, SSD or pump mount.

Specifications

3.5"/2.5" Universal drive brackets6 included, 14 positions total
Dedicated 2.5" drive brackets2 trays included, 4 positions total
5.25” drive mounts1
Expansion slots7 + 2
Front ports1 x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button
Total fan mounts9 x 120/140 mm
Front fan3 x 120/140 mm (2 x Dynamic X2 GP-14 included)
Top fan3 x 120/140 mm
Rear fan1 x 120/140 mm (1 x Dynamic X2 GP-14 included)
Bottom fan2 x 120/140 mm
Dust filtersTop, 2 x front, full length bottom
Fixed velcro strapsYes
Cable routing grommetsYes
Captive thumbscrewsHDD brackets, SSD brackets, PSU bracket
Left side panelIndustrial sound-damped steel or Tempered Glass
Right side panelIndustrial sound-damped steel
Motherboard compatibilityE-ATX (max 285 mm) / ATX / mATX / mITX
Power supply typeATX
PSU max length250 mm (with HDD cage installed)
GPU max lengthStorage layout: 290 mm - Open layout: 470 mm (445 mm w/ front fan)
CPU cooler max height185 mm
Front radiatorUp to 360/280 mm
Top radiatorUp to 360/420 mm
Rear radiator120 mm
Bottom radiatorUp to 240/280 mm
Cable routing space30 mm
Vertical GPU Support (with Flex B-20 or Flex VRC-25)65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Case dimensions (LxWxH)547 x 240 x 475 mm
Case dimensions w/o feet/protrusions/screws533 x 240 x 451 mm
Package dimensions (LxWxH)558 x 363 x 641 mm
Net weightSolid Version: 13.49 kg, TG Version: 13.45 kg
Package weightSolid Version: 15.98 kg TG Version: 15.94 kg
Volume57.7 liters


Package contentsDefine 7 case. Accessory box. User manual. Ventilated top. 4 x HDD/SSD trays (for a total of 6)
