AMD Ryzen 7 7700X3D Processor

Built for Gaming Performance

The AMD Ryzen 7 7700X3D is designed to deliver exceptional gaming performance while offering excellent value. It serves as the successor to the Ryzen 7 7800X3D, featuring AMD's 3D V-Cache technology to improve gaming performance and responsiveness.

8 Cores & 16 Threads

The processor features 8 cores and 16 threads, making it ideal for modern gaming, content creation, and multitasking workloads. It combines high efficiency with powerful multi-threaded performance.

Clock Speeds

The Ryzen 7 7700X3D operates at a 4.00 GHz base clock with a maximum boost clock of up to 4.50 GHz, delivering fast and responsive performance for demanding applications and games.

Large 3D V-Cache

The processor includes 8 MB of L2 cache and 96 MB of shared L3 cache, consisting of 32 MB on-die cache and an additional 64 MB of stacked AMD 3D V-Cache, providing lower latency and enhanced gaming performance.

Socket AM5 Compatibility

The Ryzen 7 7700X3D is compatible with all AMD Socket AM5 motherboards, including both AMD 600-series and 800-series chipsets. It supports BIOS Flashback functionality for easy compatibility updates.

Memory & PCIe Support

The processor supports dual-channel DDR5 memory and provides a 28-lane PCIe 5.0 root complex, with 24 usable lanes including 16 lanes for the primary graphics slot and two PCIe 5.0 x4 connections for CPU-attached NVMe SSDs.

120W TDP

With a 120W Thermal Design Power (TDP), the Ryzen 7 7700X3D offers powerful performance while remaining compatible with cooling solutions designed for other AMD Ryzen X3D processors.
