Akko AstroAim Magnetic Switch Pack - 45pcs
Linear Magnetic | 35 ± 5gf Initial Operating Force | Lubed
Warranty and Support
Warranty and Support
Warranty: 1 Year Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Akko AstroAim Magnetic Switch
The AstroAim magnetic switches deliver stable, shake-free keystrokes for precise control during intense gameplay. They provide a balanced typing experience that feels firm yet responsive.
The switches feature a deeper and quieter sound profile compared to Astrolink, making AstroAim an excellent choice for gamers who prefer quieter acoustics without sacrificing performance.
Specifications
Specifications
| Switch | Akko AstroAim Magnetic Switch |
| Type | Linear |
| Total Travel | 3.50 ± 0.1mm |
| Pre-travel | Customer-specific defined |
| Initial Force | 35gf Min |
| Force at 2mm | 45 ± 5gf |
| End Force | 55gf Max |
| Initial Magnetic Flux | 95 ± 15GS (PCB 1.6mm) / 110 ± 15GS (PCB 1.2mm) |
| Bottom-out Magnetic Flux |
580 ± 50GS (PCB 1.6mm) / 720 ± 50GS (PCB 1.2mm) |
| Mounting Pins | 2-pin switch |
| Materials | POM / PC / PA66 (Stem / Top / Bottom) |
| Factory Lube | Yes |
| Switch Tech | MX Style |
| Compatibility | AstroAim switches use a downward-facing N-pole magnet and are compatible with HE keyboards with the same orientation. Please check your keyboard's existing switch specifications before ordering. Not compatible with MOD007B HE / MOD007 HE YOTD v1 that use a downward-facing S-pole. |
