Silverstone SX500-G 500W 80Plus Gold Fully Modular SFX Power Supply
In stock at Computer Lounge
Couldn't load pickup availability
Warranty and Support
Warranty and Support
Warranty: 3 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
SX500-G
Support standard SFX form factor
Silent running 92mm FDB fan with 18 dBA minimum
All Japanese capacitors
High efficiency with 80 PLUS Gold certification
Class-leading single +12V rail
Strict ±3% voltage regulation and low ripple & noise
100% modular cables
All cables made with flexible flat arrays
Dual EPS 8pin with multiple PCI-E 8 / 6pin connectors support (V1.1)
Remark
- Designed for 80 PLUS Gold level of efficiency to reduce wasted heat and save on electricity.
- Built-in 92mm FDB fan has excellent airflow and low noise, perfect for quiet home or office use.
- 100% modular cable design for easy removal in a case with cable routed and tied down. SilverStone’s flexible flat cables have much greater flexibility to allow for tighter folding and management of cables.
- Powerful single +12V rail design perfect for future high-end component upgrades or overclocking. regulation and low ripple & noise performance for high stability.
Specifications
Specifications
| Product No. | SST-SX500-G |
| Color | Black (Lead-Free Paint) |
| Max. DC Output | 500W |
| Power density | 630W per liter |
| Load Range | |
| Output | |
| +3.3V | 22A (Peak: /, Min: 0A, Range: ±3%, Line Reg.: ±1%, Ripple: 50mVp-p) |
| +5V | 22A (Peak: /, Min: 0A, Range: ±3%, Line Reg.: ±1%, Ripple: 50mVp-p) |
| +12V | 41.7A (Peak: /, Min: 0A, Range: ±3%, Line Reg.: ±1%, Ripple: 120mV) |
| +5VSB | 2.5A (Peak: /, Min: 0A, Range: ±5%, Line Reg.: ±1%, Ripple: 50mVp-p) |
| -12V | 0.3A (Peak: /, Min: 0A, Range: ±10%, Line Reg.: ±1%, Ripple: 120mV) |
| Combined +3.3V & +5V | 110W |
| Combined +12V | 500W |
| Input Voltage | 90 ~ 264 Vrms |
| Input Frequency Range | 47Hz ~ 63Hz |
| PFC | Active PFC (PF>0.9 at full load) |
| Efficiency | 87%~90%（20% to 100% loading） |
| MTBF | 100,000 hours |
| Operating temperature | 0°C ~ 40°C |
| Protection | Over current protection, Over power protection, Over voltage protection, Short circuit protection, Under voltage protection |
| Connectors | V1.0: 1 x 24 / 20-Pin motherboard connector (300mm), 1 x 8 / 4-Pin EPS / ATX 12V connector (400mm), 1 x 8 / 6-Pin PCIE connector (400mm), 1 x 8 / 6-Pin PCIE connector (550mm), 6 x SATA connector ("300mm / 220mm / 100mm" x 2), 3 x 4-Pin Peripheral connector (300mm / 200mm / 200mm), 1 x 4-Pin Floppy connector (100mm) V1.1: 1 x 24 / 20-Pin motherboard connector (300mm), *1 x 8-Pin EPS and 1 x 4-Pin + 4-Pin ATX 12V connector (400mm / 150mm), 1 x 8 / 6-Pin PCIE connector (400mm), 1 x 8 / 6-Pin PCIE connector (550mm), 6 x SATA connector ("300mm / 220mm / 100mm" x 2), 3 x 4-Pin Peripheral connector (300mm / 200mm / 200mm), 1 x 4-Pin Floppy connector (100mm) |
| Cooling System | Single 92mm FDB silent fan |
| Noise Level | 18 dBA minimum |
| Certification | 80 PLUS Gold |
| Form factor | SFX |
| Dimension | 125 mm (W) x 63.5 mm (H) x 100 mm (D) |
| Weight | 1.35 kg |
| Other | GPU Support list |
