MSI MPG A850GS 850W 80Plus Gold Fully Modular Power Supply
Warranty and Support
Warranty and Support
Warranty: 1 Year Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
MPG A850GS PCIE5
Supports Nvidia® GeForce RTX™ 50 series graphics cards
Native 12V-2x6 connector
Dual-color 12V-2x6 cable
80 PLUS Gold certified
Lowest sound level, Cybenetics A++ Certification
100% all server-grade 105°C capacitors
Embossed jacket cables for improved bending and routing
Industrial-level protection with OCP, OTP, OPP, SCP, OVP, UVP, SIP, NLO
Specifications
Specifications
| Efficiency Rating | 80 PLUS Gold (up to 90%) |
| Modular | Yes (full modular) |
| Fan Size | 135 mm |
| Fan Bearing | Fluid Dynamic Bearing |
| Dimensions (DxWxH) | 150 x 150 x 86 mm |
| PFC Type | Active PFC |
| Input Voltage Range | 100-240V~ |
| Power Watt | 850W |
| Power Excursion | 1700W (*up to 200% of the PSU's rated power for 100μs) |
| Input Frequency Range | 50-60 Hz |
| Protection | OCP/ OTP/ OPP/ SCP/ OVP/ UVP/ SIP/ NLO |
| ATX (24 pin) | 1 |
| EPS (4+4 pin) | 2 |
| PCI-E 5.1 (16 pin) | 1 (600W) |
| PCI-E (6+2 pin) | 3 |
| SATA (15 pin) | 8 |
| PERIPHERAL (4 pin) | 4 |
