JDS Labs Atom DAC+
Out of Stock
Warranty and Support
Warranty and Support
Warranty: 2 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Description
Description
MEMS OSCILLATOR
Atom DAC+ is clocked by 45/49MHz MEMS oscillators with ±25ppm frequency stability, delivering minimal jitter.
UPGRADEABLE FIRMWARE
Atom DAC+'s XMOS-based firmware configures and manages all functionality, with DFU support for future updates.
UAC2 AND UAC1
Atom DAC+ supports up to 32/384kHz PCM over a custom XMOS XU208-based UAC2 engine. While we claim no measurable superiority of high sampling rates, UAC2 and ASIO support satisfy your pursuit of bit-perfect listening. UAC1 mode is activated when using a UAC1 Fallback Cable.
EXTERNALLY POWERED
Atom DAC+ is powered by a perfected supply network, with an external AC transformer and 10 regulators that ensure consistent rail voltage and super low ripple.
AUTOMATIC STANDBY
Atom DAC+ automatically enters standby after 5 minutes of USB inactivity, powering down its light ring and D/A circuitry, and audio wakes up silently and instantly.
DIFFERENTIAL SUMMING I/V OUTPUT
The differential output of an ES9018K2M DAC is paired with our unique, DC coupled precision-tuned I/V converter with three stages per channel, or six NJM opamps in total.
