Intel Xeon Silver 4309Y Processor
8 Core / 16 Thread | Base 2.8GHz | 12MB Cache | LGA 4189 | 105W TDP
Warranty and Support
Warranty and Support
Warranty: 3 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Intel® Xeon® Silver Processor
Intel® Xeon® Silver processors deliver essential performance, improved memory speed, low latency, and power efficiency. They offer the hardware-enhanced performance required for entry-level data center compute, network, and storage.
Intel® QuickAssist Technology (Intel® QAT)
Accelerate data compression and encryption while freeing up processor cores to reduce system resource consumption and TCO.
Intel® Advanced Matrix Extensions (Intel® AMX)
Accelerate your CPU’s AI capabilities with improved deep learning training and inference performance.
Intel® Trust Domain Extensions (Intel® TDX)
Increase confidentiality at the virtual machine (VM) level while enhancing privacy and control over your data.
See All Accelerator Engines
Boost performance, reduce costs, and improve power efficiency for demanding workloads with built-in Intel® Accelerator Engines.
Confidently Deploy Common and Emerging Workloads
Whether it is empowering solid foundations for AI innovation and HPC, supporting critical workloads at the edge, building a secure cloud, or helping professionals stay productive, there is an Intel Xeon processor designed to meet your organization's computing needs.
Specifications
Specifications
| Essentials | Product Collection: 3rd Gen Intel® Xeon® Scalable Processors Code Name: Products formerly Ice Lake Vertical Segment: Server Processor Number: 4309Y Lithography: 10 nm |
| CPU Specifications | Total Cores: 8 Total Threads: 16 Max Turbo Frequency: 3.60 GHz Intel SpeedStep® Max Frequency: 3.60 GHz Performance-core Base Frequency: 2.80 GHz Efficient-core Base Frequency: 2.8 MHz Processor Base Frequency: 2.80 GHz Cache: 12 MB Intel® UPI Speed: 10.4 GT/s Max # of UPI Links: 2 TDP: 105 W |
| Intel® Speed Select Technology - Performance Profile (Intel® SST-PP) | Config: 4309Y Active Cores: 8 Base Frequency: 2.8 GHz TDP: 105W Config: 4309 Active Cores: 8 Base Frequency: 2.6 GHz TDP: 95W Config: 4309 Active Cores: 8 Base Frequency: 2.3 GHz TDP: 85W |
| Supplemental Information | Marketing Status: Launched Launch Date: Q2'21 Servicing Status: Baseline Servicing Embedded Options Available: No |
| Memory Specifications | Max Memory Size (dependent on memory type): 6 TB Memory Types: DDR4-2667 Maximum Memory Speed: 2667 MHz Max # of Memory Channels: 8 Intel® Optane™ Persistent Memory Supported: No ECC Memory Supported: Yes |
| Expansion Options | Scalability: 2S PCI Express Revision: 4 Max # of PCI Express Lanes: 64 |
| Package Specifications | Sockets Supported: FCLGA4189 TCASE: 76°C Package Size: 77.5mm x 56.5mm |
| Advanced Technologies | Intel® Volume Management Device (VMD): Yes Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes Intel® Speed Select Technology - Performance Profile: Yes High Priority Cores: 0 Low Priority Cores: 0 Intel® Resource Director Technology (Intel® RDT): Yes Intel® Speed Shift Technology: Yes Intel® Turbo Boost Technology: 2 Intel® Hyper-Threading Technology: Yes Intel® Transactional Synchronization Extensions: Yes Intel® 64: Yes Instruction Set Extensions: Intel® SSE4.2 | Intel® AVX | Intel® AVX2 | Intel® AVX-512 # of AVX-512 FMA Units: 2 |
| Security & Reliability | Intel® Software Guard Extensions (Intel® SGX): Yes with Intel® SPS Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX: 8 GB Intel® Crypto Acceleration: Yes Intel® Platform Firmware Resilience Support: Yes Intel® Total Memory Encryption: Yes Intel® AES New Instructions: Yes Intel® Trusted Execution Technology: Yes Execute Disable Bit: Yes Mode-based Execute Control (MBEC): Yes Intel® Virtualization Technology (VT-x): Yes Intel® Virtualization Technology for Directed I/O (VT-d): Yes Intel® VT-x with Extended Page Tables (EPT): Yes |
