Intel Xeon Gold 6530 Processor
32 Core / 64 Thread | Base 2.1GHz | 160MB Cache | LGA 4677 | 270W TDP | 2S
Warranty and Support
Warranty and Support
Warranty: 3 Years Return to Base Warranty
Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.
Delivery and Shipping
Delivery and Shipping
All deliveries are signature required.
North Island: 1 – 2 working days
South Island: 2 – 3 working days
Please allow an additional 1 – 2 working days for delivery to rural addresses.
Buy Now, Pay Later & Finance Options:
Description
Description
Intel® Xeon® Gold Processor
Intel® Xeon® Gold processors are optimized for demanding AI, mainstream data center, multi-cloud compute, and network and storage workloads. With support for higher memory speeds and enhanced memory capacity, these processors deliver advanced performance, energy-efficient compute, enhanced memory capabilities, hardware-enhanced security, and workload acceleration.
Intel® QuickAssist Technology (Intel® QAT)
Accelerate data compression and encryption while freeing up processor cores to reduce system resource consumption and TCO.
Intel® Advanced Matrix Extensions (Intel® AMX)
Accelerate your CPU’s AI capabilities with improved deep learning training and inference performance.
Intel® Trust Domain Extensions (Intel® TDX)
Increase confidentiality at the virtual machine (VM) level while enhancing privacy and control over your data.
See All Accelerator Engines
Boost performance, reduce costs, and improve power efficiency for demanding workloads with built-in Intel® Accelerator Engines.
Confidently Deploy Common and Emerging Workloads
Whether it is empowering solid foundations for AI innovation and HPC, supporting critical workloads at the edge, building a secure cloud, or helping professionals stay productive, there is an Intel Xeon processor designed to meet your organization's computing needs.
Specifications
Specifications
| Essentials | |
| Product Collection | 5th Gen Intel® Xeon® Scalable Processors |
| Code Name | Products formerly Emerald Rapids |
| Vertical Segment | Server |
| Processor Number | 6530 |
| Lithography | Intel 7 |
| Recommended Customer Price | $2128.00-$2138.00 |
| CPU Specifications | |
| Total Cores | 32 |
| Total Threads | 64 |
| Max Turbo Frequency | 4 GHz |
| Processor Base Frequency | 2.1 GHz |
| Cache | 160 MB |
| Intel® UPI Speed | 20 GT/s |
| Max # of UPI Links | 3 |
| TDP | 270 W |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q4'23 |
| Servicing Status | Baseline Servicing |
| Embedded Options Available | Yes |
| Use Conditions | Server/Enterprise |
| Memory Specifications | |
| Max Memory Size | 4 TB |
| Memory Types | DDR5 @ 4800 MT/s (1 DPC) |
| Max # of Memory Channels | 8 |
| ECC Memory Supported | Yes |
| Expansion Options | |
| Scalability | 2S |
| PCI Express Revision | 5 |
| Max # of PCI Express Lanes | 80 |
| Package Specifications | |
| Sockets Supported | FCLGA4677 |
| Package Carrier | E1A |
| DTS Max | 91 °C |
| TCASE | 74 |
| Package Size | 77.5mm x 56.5mm |
| Advanced Technologies | |
| Intel® On Demand Activation Model | Yes |
| Intel® Data Streaming Accelerator (DSA) | 1 default devices |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Speed Select Technology - Base Frequency | Yes |
| High Priority Cores | 12 |
| High Priority Core Frequency | 2.3 GHz |
| Low Priority Cores | 20 |
| Low Priority Core Frequency | 1.9 GHz |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology ‡ | 2 |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set Extensions | Intel® AMX | Intel® SSE4.2 | Intel® AVX | Intel® AVX2 | Intel® AVX-512 |
| # of AVX-512 FMA Units | 2 |
| Security & Reliability | |
| Intel® Trust Domain Extensions (Intel® TDX) | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® SPS |
| Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX | 128 GB |
| Intel® Crypto Acceleration | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® AES New Instructions | Yes |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology ‡ | Yes |
| Execute Disable Bit ‡ | Yes |
| Intel® Boot Guard | Yes |
| Intel® Run Sure Technology | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
