Fractal Design Define 7 XL Full Tower Black Tempered Glass Dark Tint

Fractal Design  |  SKU 34580  |  MPN FD-C-DEF7X-03
$399.00 $499.00

In stock at Computer Lounge

Warranty and Support

Warranty: 2 Years Return to Base Warranty

Returns: 14-day hassle-free exchanges and store credits, subject to terms and conditions outlined in our Returns Policy.

Delivery and Shipping

All deliveries are signature required.

North Island: 1 – 2 working days
South Island: 2 – 3 working days

Please allow an additional 1 – 2 working days for delivery to rural addresses.

Buy Now, Pay Later & Finance Options:

Description

Re-defining capacity.

The Define 7 XL sets a new standard for what you should expect from a full tower case in terms of modularity, flexibility and ease of use.With its dual-layout interior, industrial sound damping and massively versatile layout supporting the largest E-ATX and enterprise boards, multi-GPU setups,outlandish water loops, and almost two dozen storage devices (in Storage layout), you’ll be hard pressed to find a limit to what you can do with your build in the Define 7 XL.


EXTRA SPACIOUS

An expansive internal layout easily accommodates large motherboards up to E-ATX and SSI-EEB.


SUPERLATIVE STORAGE

Install up to 18 HDDs alongside 5 SSDs mounts in the default Storage Layout. (6 HDD/SSD trays + 2 SSD brackets + 2 multi-brackets included)

OPEN AND INTERCHANGEABLE

  • Remove the entire top to build and route with zero hindrance. Swap in the ventilated panel to add four filtered fan positions.
  • Tool-less, top-latching panels allow quick access while preventing accidental drops


ELEGANT NEW FRONT DESIGN

Brushed aluminum encases a refined front door design with dual-handed reversible hinges and magnetic latching


SUPERIOR AIRFLOW

Three Dynamic X2 GP-14 fans come preinstalled with room to expand up to a total of 9 x 140 mm or 11 x 120 mm fans.

  • Use the Open Layout for more headroom and gargantuan water-cooling with radiators up to 480 mm in front or top and 280 mm in the base
  • Two 5.25” ODD bays can be converted to an additional front fan mount with filtered louver covering
  • Silence-optimized construction with industrial sound-damped front, top, and side panels
  • New chassis design opens up to fully expose the case interior on three sides for totally unhindered installation and cable routing
  • Three vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
  • Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
  • Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
  • Sturdy new HDD cage design with vibration damped trays
  • Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
  • Ventilated PSU shroud with two-part removable cover
  • Easy-to-clean high airflow nylon filters on the front, top, and base with full PSU coverage and convenient front access
  • 13 pass-through holes with ten rubber grommets and two removable covers make for clean cable routing regardless of motherboard size
  • Detachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board

FLEXIBLE DUAL-LAYOUT DESIGN

Convert to Open Layout and get more than enough room for your custom water loop with large reservoirs and radiators up to 480 mm.


EXCEPTIONALLY SILENT

Solid construction with industrial high-density sound damping helps maintain whisper silent operation.


VERSATILE NEW MULTI-BRACKETS

The included multi-bracket lets you convert any unused fan position to an HDD, SSD or pump mount.

Specifications

3.5"/2.5" Universal drive brackets6 + 2 included, 18 positions total
Dedicated 2.5" drive brackets2 included, 5 positions total
5.25” drive mounts2
Expansion slots9 + 3
Front ports1 x USB 3.2 Gen 2x2 Type-C (20 Gbps), 2 x USB 3.0, 2 x USB 2.0, Audio I/O, Power button, Reset button
Total fan mounts11 x 120 mm or 9 x 140 mm
Front fan4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included)
Top fan4 x 120 mm or 3 x 140 mm
Rear fan1 x 120/140 mm, (1 x Dynamic X2 GP-14 included)
Bottom fan2 x 120/140 mm
Dust filtersTop, 2 x Front, Bottom + PSU
Fixed velcro strapsYes
Cable routing grommetsYes
Captive thumbscrewsHDD brackets, SSD brackets, PSU bracket
Left side panelIndustrial sound-damped steel or Tempered Glass
Right side panelIndustrial sound-damped steel
Motherboard compatibilityE-ATX / ATX / mATX / mITX / EE-ATX / SSI-CEB / SSI-EEB
Power supply typeATX
PSU max length250 mm (both HDD cages installed)
GPU max lengthStorage layout: 340 mm - Open layout: 530 mm (505 mm w/ front fan)
CPU cooler max height185 mm
Front radiatorUp to 480/420 mm
Top radiatorUp to 480/420 mm
Rear radiator120 mm
Bottom radiatorUp to 240/280 mm
Cable routing space30 mm
Vertical GPU Support (with Flex B-20 or Flex VRC-25)65mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Case dimensions (LxWxH)604 x 240 x 566 mm
Case dimensions w/o feet/protrusions/screws590 x 240 x 548 mm
Package dimensions (LxWxH)646 x 357 x 708 mm
Net weightSolid Version: 16.53 kg, TG Version: 16.64 kg
Package weightSolid Version: 18.73 kg, TG Version: 18.84 kg
Volume77.6 liters
Package contentsDefine 7 XL - Accessory box - User manual - Ventilated top panel - ODD bracket - ODD bay cover - 2 x HDD/SSD trays
EANSolid: 7340172702047, TG Dark Tint: 7340172702061, TG Light Tint: 7340172702054
UPCSolid: 843276102043 TG Dark Tint: 843276102067, TG Light Tint: 843276102050
