ASUS PRIME B860-PLUS WIFI-CSM Motherboard

ASUS PRIME series motherboards

ASUS PRIME series motherboards are expertly engineered to unleash the full potential of the latest Intel® Core™ Ultra Processors (Series 2). Boasting a robust power design, comprehensive cooling solutions, and intelligent tuning options, the PRIME B860-PLUS WIFI-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.
*CEC Tier II ready

ASUS Corporate Stable Model

ASUS Corporate Stable Model (CSM) is a commercial program designed to provide stable and reliable motherboards. Offering up to 36-month product lifecycle support and 6-month end-of-life notice to allow sufficient lead times for your organization to get ready for product transitions. Each purchase of an ASUS CSM motherboard comes with ASUS Control Center Express - server-grade IT management software.

ASUS Control Center Express

ASUS Control Center Express is an integrated IT monitoring and management software designed to deploy faster, simplify IT operations, and improve productivity with comprehensive control and user-friendly functions. ASUS Control Center Express is compatible with over 100 ASUS motherboards to provide a high-quality, TCO-optimized solution for your business needs.

AI Solutions

ASUS AI Solutions include AI Advisor as your technical expert with expertise in PC performance.

Robust Power Design

Stable power is crucial for maximizing the performance of Intel® Core™ Ultra Processors (Series 2). The PRIME B860-PLUS WIFI-CSM is designed to meet the needs of high-core-count CPUs. It features 8(80A) + 1(80A) + 1(80A) + 1(80A) power stages that integrate high-side and low-side MOSFETs and drivers into packages rated for up to 80 amperes each. This configuration ensures optimal power delivery, efficiency, stability, and performance for both current and future Intel® processors.

• Six-layer PCB design: The multi-layered printed circuit board design quickly dissipates heat around the voltage regulators to improve overall system stability and provide the CPU with more overclocking headroom.
• ProCool connector: Proprietary connectors augment the motherboard’s link to the power supply with an 8-pin connector that passes 12 volts of power directly to the processor. Each connector features solid pins that can handle more current than hollow-pin connectors.
• Power Saving: Optimize power with CPU, lighting, and fan settings.
• Digi+ VRM control: The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop, automatically switching frequency and power-efficiency settings.



AEMP III for Ultimate DDR5 Performance

ASUS Enhanced Memory Profile III (AEMP III) empowers users to achieve unparalleled memory performance with cutting-edge CUDIMM memory through a two-phase tuning process, optimizing the clock driver and memory frequency for peak performance and stability at DDR5-7600 or higher.

DIMM Fit

DIMM Fit analyzes memory modules to optimize performance and pinpoint potential issues, ensuring peak efficiency, compatibility, and system stability for overclockers, gamers, and content creators alike.

Two M.2 slots (up to 128Gbps)

The PRIME B860-PLUS WIFI-CSM offers a total of two M.2 slots, including one that supports data-transfer speeds of up to 128Gbps via PCIe 5.0, and another that supports 64Gbps via PCIe 4.0, enabling faster boot-up and app load times.

Cooler by Design

The PRIME B860-PLUS WIFI-CSM motherboard is engineered with multiple onboard heatsinks and hybrid fan headers for optimal cooling under intense workloads.

ASUS Fan Xpert 2+

Provides comprehensive fan control, including Auto-Tuning for parameter configuration, Extreme Quiet mode for reduced noise, and UEFI BIOS fan controls.

Empowering Connections

This motherboard offers a versatile range of connectivity, including support for WiFi 6E, PCIe 5.0 slot, and an arsenal of USB ports, including Type-C® connections.

• WiFi 6E: Built-in WiFi 6E4 technology takes advantage of the newly available radio spectrum in the 6 GHz band. With triple the bandwidth of the 2.4/5/6 GHz band, WiFi 6E delivers ultrafast wireless networking speeds with improved capacity and better performance in dense wireless environments.
• USB 20Gbps port: A batch of USB ports supports high-end rigs loaded with peripherals, including a rear USB Type-C® port with transmission speeds of up to 20Gbps.
• PCIe 5.0 slot: The latest processors introduce PCIe 5.0 support, doubling data transfer speeds compared to PCIe 4.0, enhancing signal integrity, and providing backward-compatible CEM connectors and support for previous PCIe versions.



Personalization

The PRIME B860-PLUS WIFI-CSM enhances the user experience across the board, from simplifying BIOS setting adjustments to offering customizable RGB lighting controls for a uniquely personal system aesthetic.

DIY Friendly

The PRIME B860-PLUS WIFI-CSM motherboard features EZ PC DIY innovations that simplify and speed up the PC building process, making DIY easy and convenient.
